SECTION 1 - BASE
3121229 10MSP 13
FIGURE 1-2. DRIVE ASSEMBLY
ITEM PART NUMBER QTY DESCRIPTION REV
3160323 Ref SPINDLE/HUB ASSEMBLY
1 3160323 1 Spindle
2 7024756 1 Hub
3 7024758 1 Ring, Input
4 70000210 1 Gear, Input Sun
5 70000210 3 Gear, Input Planet
6 70000210 3 Pin, Input Planet
7 70000210 1 Carrier
8 70000210 1 Gear, Output Sun
9 70000212 3 Gear, Output Planet
10 70000212 3 Pin, Output Planet
11 7024747 1 Cover
14 See Note 2 Bearing (Note: Use Items 201, 203, 205 & 206)
16 See Note 1 Seal, Lip (Note: Use Items 201 & 205)
17 70000215 1 Seal, Lip
18 70000210 3 Ring, Retaining
19 7024747 1 Ring, Retaining
20 70000191 1 O-Ring
21 7024747 1 Thrustwasher
23 70000210 1 Plate, Thrust
24 70000210 1 Ring, Retaining
25 See Note 6 Thrustwasher (Note: Use Items 202 & 206)
26 See Note 3 Bushing, Planet (Note: Use Items 202 & 206)
27 See Note 1 Ring, Retaining (Note: Use Items 203 & 205)
29 7024747 2 Plug
32 70000212 3 Thrustwasher, Tanged
3160323 Ref DRIVE MOTOR ASSEMBLY B
101 3160323 1 Hub/Spindle Assembly (Includes Items 1-32)
102 70000211 1 Electric Motor Assembly
102A 70000213 4 Brush
102B 70000213 1 Indicator, Wear (Not Shown)
102C 70000213 4 Spring, Brush
102D 70000213 1 Bearing (Not Shown)
103 70000214 1 Brake Assembly
103A 70000935 1 Disc, Brake (Part of Kit)
106 70000211 2 Bolt
107 70000214 3 Bolt
Ref KIT OPTIONS:
Ref Repair Kit Options:
200 7024747 1 Cover Kit (Includes Items 11, 19-21 & 29)
201 7024748 1 Main Seal and Bearing Kit (Includes Items 14, 16 & 20)
202 70000210 1 Input Carrier Kit (Includes Items 4-8, 18, 20 & 23-26)
203 7024758 1 Input Ring Kit (Includes Items 3, 14, 20 & 27)
204 70000211 1 Motor Kit (Includes Items 17, 102 & 106)
205 7024756 1 Hub Kit (Includes Items 2, 14, 16, 20 & 27)
206 70000212 1 Output Planet Kit (Includes Items 9, 10, 14, 20, 25, 26 & 32)
207 70000213 1 Brush and Bearing Kit (Includes Items 102A-102D)
208 70000214 1 Brake Kit (Includes Items 103 & 107)
