SECTION 2 - CONTROLS
3121229 10MSP 33
FIGURE 2-5. GROUND COMPONENTS INSTALLATIONS
ITEM PART NUMBER QTY DESCRIPTION REV
Ref GROUND CONTROLS INSTALLATION
0274894 Ref All Specs except Australian/Japanese and Chinese Specs C
0274894 Ref Australian Spec (Prior to SN 0130017845) C
1001137013 Ref Australian Spec (SN 0130017845 to Present) A
0274895 Ref Japanese and Chinese Specs Only C
1 0100011 AR Locking Compound
2 0140033 1 Alarm
3 0641404 2 Bolt 1/4in-20NC x 1/2in
4 Ref Module, Traction Options:
4 1001102847 1 Module, Traction (was p/n 1600397/p/n 1600451) (Prior to SN
0130014947)
4 1001102847 1 Module, Traction (SN 0130014947 to Present)
5 Ref Module, Ground Control Station Options:
5 1600435 1 All Specs except Australian/Japanese and Chinese Specs
5 1600435 1 Australian Spec (Prior to SN 0130017845)
5 1001136954 1 Australian Spec (SN 0130017845 to Present)
5 1600436 1 Japanese and Chinese Specs Only
5A 7024428 1 Emergency Stop Switch Assy
5B Ref Selector Switch Assy Options:
5B 7024430 1 All Specs (Australian Spec) (Prior to SN 0130017845)
5B 7024591 1 Australian Spec (SN 0130017845 to Present)
5C Ref Cover Assy Options:
5C 7024460 1 All Specs (Australian Spec) (Prior to SN 0130017845)
5C 7024592 1 Australian Spec (SN 0130017845 to Present)
6 3911020 4 Screw #10-24NC x 1-1/4in
7 4751000 4 Flatwasher #10
