SECTION 2 - CONTROLS
3121229
10MSP
23
FIGURE 2-2. BATTERY CHARGER AND PLUG INSTALLATION (Prior to SN 0130010886)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
BATTERY CHARGER INSTALLATIONS
0274897
Ref
ANSI - Charger with Plug
C
0274898
Ref
Australian - Charger without Plug
B
0274899
Ref
ANSI - Charger without Plug
C
0274900
Ref
ANSI - Charger with Plug/Cord Reel
C
1
0100011
AR
Locking Compound
2
0400241
1
Battery Charger Assembly (No Serviceable Parts Available)
3
0610131
1
LED Board
4
1060689
1
Cord, Electrical
5
3911016
4
Screw #10-24NC x 1in
5
3311001
2
Nut #10-24NC (Charger with Australian Plug Only)
6
4191706
4
Screw 6mm x 12mm
7
Ref
Cover, Terminal Options:
7
4460802
1
Charger with Plug
7
4460802
1
Charger without Plug
7
Not Required
0
Charger with Plug/Cord Reel
8
Ref
Terminal, Inlet Options:
8A
4460803
1
Charger with ANSI Plug
8A
4460940
1
Charger with Australian Plug
8A
Not Required
0
Charger without Plug
8B
4120046
1
Socket, Cord Reel Stop (Charger with ANSI Plug/Cord Reel
Only)
Ref
Note: Items 20-23 used with Charger with Plug/Cord Reel
only.
20
3680057
1
Reel, Charger Cord
20A
0791508
1
Screw 5/16in-18NC x 1in
21
4751500
1
Flatwasher 5/16in Wide
22
0791406
1
Screw 1/4in-20NC x 3/4in
23
3575423
1
Angle, Mounting
101
2915230
1
BATTERY CHARGER REPROGRAM CONTROLLER KIT (was
p/n 1600466)
