SECTION 3 - MAST
42
10MSP
3121229
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
45
4567491
2
Tube, Spacer
46
4567750
1
Tube, Spacer
47
4567751
1
Tube, Spacer
48
4740007
2
Washer, Thrust
49
4740414
4
Washer, Cup
50
4751000
8
Flatwasher #10 Wide
51
4751500
2
Flatwasher 5/16in Wide
52
4569003
3
Tube, Spacer
0273417
1
Mast Kit (Includes Items 17-20)
G
1260375
Ref
CHAIN ASSEMBLY - #446 CHAIN
B
101
0100062
AR
Loctite #RC/640
102
0561153
2
Block, Chain Anchor
103
0561409
2
Block, Chain Anchor
104
Purchased Assy
AR
Chain
105
3422338
2
Pin, Equalizer
106
3422346
4
Pin, Grooved
107
3450304
2
Pin, Cotter
108
3571101
1
Plate, Chain Adjustment
109
4300111
2
Stud
110
4751500
2
Flatwasher 5/16in
1260376
Ref
CHAIN ASSEMBLY - #444 CHAIN
C
201
0100019
AR
Loctite #RC/640 (was p/n 0100062)
202
0561149
2
Block, Chain Anchor
203
0561408
2
Block, Chain Anchor
204
Purchased Assy
AR
Chain
205
3422338
2
Pin, Equalizer
206
3422346
2
Pin, Grooved
207
3452355
2
Pin, Grooved
208
3450304
2
Pin, Cotter
209
3571103
1
Plate, Chain Adjustment
210
4300111
2
Stud
211
4751500
2
Flatwasher 5/16in
0273545
Ref
MAST INSTALLATION
B
301
0100019
AR
Locking Compound
302
0641609
3
Bolt 3/8in-16NC x 1-1/8in
304
3311601
4
Nut 3/8in-16NC
305
4711600
8
Flatwasher 3/8in Narrow
306
0641612
1
Bolt 3/8in-16NC x 1-1/2in
