7-16 – JLG Lift – 3124288
17B Not Available Connector, Female 6 Position 1
Not Available Pin, Male 6
18 to 19 Not Used
20 4240033 Tie-Strap (Not Shown) A/R
21 Not Used
22 Bolt Options: 3
0641405 Bolt 1/4”-20NC x 5/8” (Prior to S/N 0200119881)
0641415 Bolt 1/4”-20NC x 1 7/8” (S/N 0200119881 to Present)
FIGURE 7-5. LOAD SENSING SYSTEM INSTALLATION (3394RT/4394RT) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
