7-4 – JLG Lift – 3124288
33A 4460836 Plug, Male 12 Position 1
4460465 Socket, Female 4
4460466 Seal, Plug 8
0840055 Boot 1
33B 4460897 Connector, Female 2 Position 1
4460464 Pin, Male 2
33C 4460932 Connector, Female 4 Position 1
4460464 Pin, Male 4
33D 4460049 Connector, Strain Relief 1
34 1061020 Cable, Extension (E/M3369/4069LE Only) 2 B
34A Not Available Plug, Male 6 Position 1
Not Available Socket, Female 6
34B Not Available Connector, Female 6 Position 1
Not Available Pin, Male 6
SCISSOR ARMS INSTALLATIONS WITH LSS (LE ONLY) Ref.
1001110710 260MRT Ref. A
0275525 3369LE Ref. A
0275526 4069LE Ref. A
159 Load Sensing Harness Options:
4922915 260MRT (S/N 0200193881 to Present) A
4922903 E/M3369/4069LE (S/N 0200152398 to Present) B
FIGURE 7-1. LOAD SENSING SYSTEM INSTALLATION (260MRT, M3369/M4069 & 3369LE/4069LE)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
