ENGINE & ATTACHING PARTS
TF6-42 91504001 4-8
51 88521010 4 HEX LOCKNUT, 5/8-11
52 91406026 1 LH FRONT ENGINE MOUNT
53 83191043 2 HEX HD CAPSCREW, M16X2X30, (torque to 166-181 lb-ft)
54 83783030 2 LOCKWASHER, M16
55 91143315 1 OIL PRESSURE SENDER
56 83191013 11 LOCKWASHER, M10
57 88991001 1 O-RING
58 14403364 AR LOCTITE, 242
59 14404043 AR LOCTITE, 545
91415084 1 250 HOUR FILTER KIT, (includes all items)
91534005 1 OIL FILTER ELEMENT
91404004 1 FUEL FILTER
1101313 1 AIR FILTER SAFETY ELEMENT
1101312 1 AIR FILTER ELEMENT
91083218 1 FUEL STRAINER
91534006 1 OIL FILTER SEAL
2915175 1 1000 HOUR FILTER KIT, (includes 91415084 & the following)
1001093626 1 HYDRAULIC FILTER
1340021 1 HYDRAULIC BREATHER
91474250 1 TRANSMISSION FILTER
NOTE: ITEM NUMBERS NOT LISTED ARE NOT USED ON THIS FIGURE
Figure 4-1 Engine Assembly, L.H. View
Item Part Number Qty. Description Rev.
S/N 0160003136 & After
