OPTIONS
TF6-42
91504001
12-4
Figure 12-1 Heater Option Assembly
Item
Part Number
Qty.
Description
Rev.
91475067
Ref
HEATER OPTION ASSY W/STANDARD SEAT, (includes items 1 thru 24 and
items 26 thru 60)
91475068
Ref
HEATER OPTION ASSY W/SUSPENSION SEAT, (includes items 1 thru 25 and
items 27 thru 60)
1
80373046
1
FITTING
2
91083155
1
TRUCK VALVE
3
77383540
1
COOLANT RESTRICTER ORIFICE
4
82033995
20’
HEATER HOSE, 5/8
5
Ref
ENGINE ASSY, (see Section 4 for details)
6
86671187
2
HEATER HOSE CLAMP
7
91403539
2
CONNECTOR, 3 WAY
8
80683073
1
FITTING, ADAPTER
9
91403443
1
90 DEGREES, BARBED FITTING
10
80963058
1
W. PACK CONNECTOR, (shroud)
11
80963069
2
W. PACK CONNECTOR, (pins)
12
80963065
2
W. PACK CONNECTOR, (seals)
13
77363265
1
RELAY
14
8229262
2
AUTO FUSE, 25 AMP
15
84231107
18
HOSE CLAMP
16
80963101
1
WIPER SWITCH
17
83683085
1
WIPER BOTTLE
18
88201005
3
HEX HD CAPSCREW, 1/4-20X1, GR5
19
88561002
25
FLAT WASHER, 1/4
20
88551009
24
LOCKWASHER, 1/4
21
88501004
2
HEX NUT, 1/4-20
22
91403351
1
WIPE/WASH HARNESS
23
91403352
1
HEATER HARNESS
24
91403350
1
WIPE/HEATER HARNESS
25
91406114
1
HEATER COVER WELDMENT, (used with suspension seat option)
26
91406113
1
ACCESS, BEZEL COVER, (used with standard seat)
27
70022804
1
HEATER FAN MOTOR REPLACEMENT KIT
28
88261015
20
SOCKET BUTTON HD CAPSCREW, 1/4-20X5/8
29
71492152
1
VENT HOSE, 2-1/2
30
91401421
1
VENT COVER
31
91406119
1
HEATER COVER WELDMENT
32
91403288
1
RH CONSOLE W/HEATER
33
86971172
4
HOSE CLAMP
34
83683182
1
WATER VALVE
35
91413038
1
HEATER CONTROL CABLE
36
80363029
1
KNOB, 1/4 SHAFT
37
80964001
1
BLOWER SWITCH
38
80363069
1
KNOB, 3/16 SHAFT
39
80363028
1
ROTARY CONTROL
40
91403608
1
DEFROSTER FAN
41
91401443
1
FAN BASE PLATE
42
91033425
1
RUBBER GROMMET
43
88211030
4
SOCKET HD CAPSCREW, #10-24X3/4, GR8
44
77143017
4
WHIZ-LOC NUT, #10-24
45
91403299
1
DASH, ENCLOSED CAB
S/N 0192001 thru 0192007 &
0160000052 thru 0160013828
