Page 246
CAB
TF6-42
91504001
6-8
Figure 6-2 Cab Enclosure w/Heater Option
Item
Part Number
Qty.
Description
Rev.
91475108
1
CAB ENCLOSURE KIT INSTALLATION, (includes items 1 thru 55)
A
1
80373046
1
FITTING
2
91083155
1
TRUCK VALVE
3
77383540
1
COOLANT RESTRICTOR ORIFICE
4
82033995
17’
HEATER HOSE, 5/8”
5
86671187
2
HEATER HOSE CLAMP
6
86683122
1
TIE WRAP
7
80683073
1
ADAPTER FITTING
8
91403443
1
BARBED FITTING, 90 DEGREES
9
Ref
R.H. CONSOLE, (see Figure 6-5 for details)
10
86683193
4
HOSE CLAMP
11
83683182
1
WATER VALVE
12
91413038
1
HEATER CABLE
13
80363029
1
KNOB, 1/4 SHAFT
14
80964001
1
BLOWER SWITCH
15
80363069
1
KNOB, 3/16 SHAFT
16
80363028
1
ROTARY CONTROL
17
80963058
1
WEATHERPACK SHROUD
18
80963069
2
WEATHERPACK PINS
19
80963065
2
WEATHERPACK SEALS
20
91403351
1
WIPER/WASHER HARNESS
21
91403352
1
HEATER HARNESS
22
91403350
1
WIPER/HEATER HARNESS
23
83683085
1
WASHER BOTTLE
24
77363265
1
RELAY
25
8229262
2
AUTO FUSE, 25 AMP
27
80963101
1
WIPER SWITCH
28
88201005
3
HEX HD CAPSCREW, 1/4-20X1
29
88561002
9
FLAT WASHER, 1/4
30
88551009
8
LOCKWASHER, 1/4
31
88501004
2
HEX NUT, 1/4-20
32
91413036
2
SELF TAPPING SCREW, #6X1/2
33
24861170
2
CLAMP
34
88561105
2
FLATWASHER, #10
35
71492150
10’
VENT HOSE, 2” DIAMETER
36
71492152
10.5’
VENT HOSE, 2 1/2” DIAMETER
37
84231107
18
HOSE CLAMP
38
91403539
2
3 WAY CONNECTOR
39
91473156
1
CAB ENCLOSURE, (includes all items on Figures 6-2 thru 6-4)
40
91403445
1
HEATER CONTROL PANEL
41
91403329
1
HEAT/AC PLENUM
42
88201011
1
HEX HD CAPSCREW, 1/4-20X2 1/2
43
77133279
1
CLAMP SET
44
77133137
1
COVER PLATE
45
88201023
1
HEX HD CAPSCREW, 5/16-18X1 3/4
46
91403280
1
HEATER UNIT
47
88261015
4
BUTTON HD CAPSCREW, 1/4-20X5/8
48
91413053
3
RECTANGULAR VENT
49
91403596
2
VENT REDUCER
S/N 0160013983 & After
