RECOMMENDED SPARE PARTS
The following list will service fleets of machines (built to current production per date on the front cover) with repair
parts which can be installed in the field. Parts from the list should be replaced when inventory is depleted to keep
service parts stock supplied. For further information, contact your JLG dealer or the JLG Industries Parts Department.
TF6-42
91504001
13-2
DRIVE TRAIN
FNR Shifter, 3-Speed, (see Figure 7-2)
1
FNR Shifter, 4-Speed, (see Figure 7-2)
1
Wheel End Seal, (see Section 5), (S/N 0192001 thru 0160000157)
4
Wheel End Seal, (see Section 5), (S/N 0160000170 & After)
4
Wheel End Bushing, (see Section 5), (S/N 0192001 thru 0160000157)
4
Wheel End Bushing, (see Section 5), (S/N 0160000170 & After)
4
Wheel Hub Seal, (see Section 5), (S/N 0192001 thru 0160000157)
2
Wheel Hub Seal, (see Section 5), (S/N 0160000170 & After)
2
Universal Joint Kit, (see Section 5)
4
HYDRAULIC SYSTEM
Boom Joystick Assy, (see Figure 7-6), (S/N 0192001 thru 0160000157)
1
Boom Joystick Assy, (see Figure 7-6), (S/N 0160000170 & After)
1
Boom Joystick Handle Assy, (see Figure 7-6)
1
Lift Cyl Seal Kit, (see Figure 9-1), (S/N 0192001 thru 0160009242)
1
Lift Cyl Seal Kit, (see Figure 9-1), (S/N 0160010695 & After)
1
Crowd Cyl Seal Kit, (see Figure 9-2)
1
Tilt Cyl Seal Kit, (see Figure 9-3)
1
Comp Cyl Seal Kit, (see Figure 9-4)
1
Sway Cyl Seal Kit, (see Figure 9-5)
1
Stabilizer Cyl Seal Kit, (see Figure 9-6)
1
Hydraulic Filter Seal Kit, (see Figure 9-10)
1
Tank Filter, (see Figure 9-10)
1
Breather, (see Figure 9-10)
1
Fluid Level Gauge, (see Figure 9-10)
1
Bar Gauge, (see Figure 9-10)
1
ELECTRICAL
Water Temp. Sender, (see Figure 4-1)
1
Transmission Temp. Switch, (see Figure 4-1), (S/N 0192001 thru 0160002052)
1
Transmission Temp. Switch, (see Figure 4-2), (S/N 0160002069 & After)
1
Oil Press. Switch, (see Figure 4-1)
1
Oil Press. Sender, (see Figure 4-1)
1
Fuel Level Sender, (see Figure 4-4)
1
Starter Relay, (see Figure 4-1)
1
Backup Alarm, (see Figure 1-1)
1
Start/Aux Switch, (see Figure 6-7)
1
Alternator, (see Figure 4-2)
1
Regulator, (see Figure 4-2)
1
Starter Kit, (see Figure 12-22), (S/N 0192001 thru 0160006622)
1
Starter, (see Figure 4-3), (S/N 0160006707 & After)
1
Starter Solenoid, (see Figure 4-2), (S/N 0192001 thru 0160006622)
1
Horn, (see Figure 1-1)
1
Part Number
Description
Qty./Machine
