2.1.4 TECHNICAL SPECIFICATIONS
NB: Side extension is measured from the centre of the turntable to the outside edge of the
basket.
X19JR0620113 14
BOOM LIFT MODELS X19J
JLG
PLATFORM CAPACITY 200 kg 120 kg
PLATFORM HEIGHT (floor) 14,96 m 16,67 m
MAX WORKING HEIGHT 17,06 m 18,77 m
STANDARD BASKET DIMENSIONS 1335 x 690 x H1100 mm
HORIZONTAL EXTENSION 4,30 m 5,90 m
MAX HORIZONTAL OUTREACH 4,80 m 6,40 m
ROTATION (non-continuous) 360° 360°
BASKET ROTATION 124° (+/- 62°)
MAX GROUND REACTION FORCE FOR EACH STABILISER 1330 daN
MAX GROUND PRESSURE FOR EACH STABILISER 1,9 daN/cm 2
NO. OF OPERATORS 2 1
NO. OF OPERATORS WITH OPTIONAL SINGLE-OPERATOR BASKET 1 1
JIB - TYPE OF ARTICULATED JOINT 82,7°(+0°/-82,7°)
MAX WORKING GRADIENT 1°/1,75%
MAX STABILISATION SLOPE 11°
TOTAL WEIGHT IN TRANSPORT CONFIGURATION 2098 kg
ENGINE
HONDA iGX440 - 12,7 CV - 3600 rpm
HATZ 1B40 - 10 CV - 3600 rpm
ELECTRIC MOTOR
2,2 kw/230V/50Hz 1500 rpm
2,2 kw/230V/50Hz 1500 rpm (Optional)
ELECTRICAL SYSTEM VOLTAGE 12 V
PUMPS 2x3,15 cc
MAX TRAVEL SPEED HONDA petrol engine (1,7) 1,3 km/h
MAX TRAVEL SPEED HATZ diesel engine (1,3) 1,1 km/h
MAX TRAVEL SPEED HONDA engine with optional 2nd speed 1,7 / 3,3 km/h
MAX TRAVEL SPEED HATZ engine with optional 2nd speed 1,3 / 2,6 km/h
TRAVEL/STAB. SYSTEM PRESSURE 165 bar
AERIAL PART SYSTEM PRESSURE 210 bar
MAX SLOPE ALLOWED IN TRAVEL DIRECTION 15°
MAX WIND SPEED 12,5 m/s
MAX MANUAL FORCE ALLOWED 400 N
