Page 63
SECTION 4 - BOOM & PLATFORM
3121810
– JLG Lift –
4-15
Table 4-2.Boom Marking Tape Installation
w/o Boom Wipers
Model
Dim. A
Dim. B
Dim.C
100SX Single Capacity (CE/Aus)
N/A
90 in. (228.6 cm)
123 in. (312.4 cm)
100SX Dual Capacity (CSA)
51-1/4 in. (130.2 cm)
90 in. (228.6 cm)
123 in. (312.4 cm)
110SXJ Single Capacity (CE/Aus)
N/A
58-3/8 in. (148.2 cm)
93-3/4 in. (238.1 cm)
110SXJ Single Capacity (CSA)
N/A
78-3/8 in. (199.1 cm)
129-3/8 in. (328.6 cm)
110SX Single Capacity (CE/Aus)
N/A
105-1/2 in. (267.9 cm)
140-1/2 in. (356.8 cm)
110SX Dual Capacity (CSA)
85-1/2 in. (217 cm)
122-1/2 in. (311.2 cm)
160-1/2 in. (407.7 cm)
120SXJ Single Capacity (CSA)
N/A
54-7/8 in. (139.4 cm)
90 in. (228.6 cm)
120SXJ Single Capacity (CE/Aus)
N/A
34-7/8 in. (88.5 cm)
70 in. (177.8 cm)
w/Boom Wipers
Model
Dim. A
Dim. B
Dim. C
100SX Single Capacity (CE/Aus)
N/A
87-7/8 in. (223.2 cm)
120-7/8 in. (307.8 cm)
100SX Dual Capacity (CSA)
49-1/8 in (124.8 cm)
87-7/8 in. (223.2 cm)
120-7/8 in. (307.8 cm)
110SXJ Single Capacity (CE/Aus)
N/A
56-3/8 in. (143.2 cm)
91-3/4 in. (233.0 cm)
110SXJ Single Capacity (CSA)
N/A
76-3/8 in. (193.9 cm)
127-3/8 in. (323.5 cm)
110SX Single Capacity (CE/Aus)
N/A
103-3/8 in. (262.5 cm)
138-3/8 in. (351.5 cm)
110SX Dual Capacity (CSA)
83-3/8 in. (211.8 cm)
120-3/8 in. (305.8 cm)
158-3/8 in. (402.3 cm)
120SXJ Single Capacity (CSA)
N/A
52-7/8 in. (134.3 cm)
88 in. (223.5 cm)
120SXJ Single Capacity (CE/Aus)
N/A
32-7/8 in. (83.5 cm)
68 in. (172.7 cm)
