SECTION 1 - SPECIFICATIONS
3121810 – JLG Lift – 1-7
1.7 PRESSURE SETTINGS
Main Valve
Main - 238 bar (3450 psi)
Lift Down - 103 bar (1500 psi)
Jib (Up) - 207 bar (3000 psi)
Jib (Down) - 97 bar (1400 psi)
Swing - 83 bar (1200 psi)
Platform Level Up - 152 bar (2200 psi)
Platform Level Down - 172 bar (2500 psi)
Drive - 310 bar (4500 psi)
Steer - 197 bar (2850 psi)
Platform Rotate - 172 bar (2500 psi)
Extendable Axles In - 172 bar (2500 psi)
Extendable Axles Out - 172 bar (2500 psi)
NOTE: Refer to Section 2 for pressure setting procedures.
1.8 FUNCTION SPEEDS (IN SECONDS)
100SX
Lift Up - 100-85
Lift Down - 100-75
Swing Right & Left - 200-140
Telescope Out - 93-74
Platform Rotate Right & Left - 20-10
Drive (61 m) - 57-47
Drive above Horizontal (15.2 m) - 89-96
110SX
Lift Up - 100-85
Lift Down - 100-75
Swing Right & Left - 200-140
Telescope Out - 100-80
Platform Rotate Right & Left - 20-10
Drive (61 m) - 57-47
Drive above Horizontal (15.2 m) - 89-96
110SXJ
Lift Up - 100-85
Lift Down - 100-75
Swing Right & Left - 200-140
Telescope Out - 93-74
Platform Rotate Right & Left - 24-36
Articulated Jib Up - 15-20
Articulated Jib Down - 45-55
Drive (61 m) - 56-46
Drive above Horizontal (15.2 m) - 89-96
120SXJ
Lift Up - 100-85
Lift Down - 100-75
Swing Right & Left - 200-140
Telescope Out - 100-80
Platform Rotate Right & Left - 24-36
Articulated Jib Up - 15-20
Articulated Jib Down - 45-55
Drive (61 m) - 56-46
Drive above Horizontal (15.2 m) - 89-96
