9-2 3120820
SECTION 9 RECOMMENDED SERVICE PARTS STOCK
S
E
C
T
I
O
N
9
R
E
C
O
M
M
E
N
D
E
D
S
E
R
V
I
C
E
P
A
R
T
S
S
T
O
C
K
MODELS EURO 120HX
The following list will service fleets of machines (built to current production per date on the front cover) with
emergency repair parts which can be installed in the field. Parts from the list should be replaced when inven-
tory is depleted to keep service parts stock supplied. For further information, contact your JLG dealer or the
JLG Industries Parts Department.
JLG PART
NUMBER
DESCRIPTION
QTY PER FLEET
1-10 10-20 20 OR MORE
7029274 Filter, Engine Fuel (Deutz) (Figure 2-14) 1 1 1
7014503 Filter, Engine Oil (Deutz) (Figure 2-14) 1 case 1 case 1 case
1660183 Coupling (Deutz) (Figure 2-16) 1 1 1
1660233 Coupling (Deutz) (Figure 2-16) 1 1 1
2120129 Element, Hydraulic Oil Filter (Figure 2-20) 4 8 12
1340046 Breather, Hydraulic (Figure 2-20) 1 1 1
7006138 Pin Kit - Powertrack (Figure 3-1) 24 24 24
7000638 Switch (Figure 3-5) 1 1 1
7000647 Cable (Figure 3-5) 1 1 1
2940006 Latch, Door (Figure 4-1) 1 1 1
4360031 Footswitch (Figure 4-1) 1 1 1
4360336 Switch, Toggle (Figure 4-4) 1 1 1
1600277 Controller, PQ (Figure 4-4) 1 1 1
7020512 Board, Circuit - 1600155 Controller (Figure 4-4) 1 1 1
7003797 Board, Circuit - 1600135 Controller (Figure 4-4) 1 1 1
7003789 Switch, Steer - 1600135 Controller (Figure 4-4) 1 1 1
4360161 Breaker, Circuit - 20 Amp (Figure 4-4) 1 1 1
4360057 Switch, Limit (Figures 4-5 & 7-3) 1 1 1
3990010 Diode - 6 Amp (Figure 7-3) 1 1 1
VARIABLE PARTS
7006193 Powertrack Repair Section Without Chip Covers - Left Side
(Figure 3-1) 1 1 1
7006196 Powertrack Repair Section With Chip Covers - Left Side
(Figure 3-1) 1 1 1
7006153 Powertrack Repair Section Without Chip Covers - Right
Side (Figure 3-1) 1 1 1
7006145 Powertrack Repair Section With Chip Covers - Right Side
(Figure 3-1) 1 1 1
1693405 Relay (French Spec Only) (Figure 7-3) 1 1 1
3740057 Relay (Italian Spec Only) (Figure 7-3) 1 1 1
