SECTION 7 ELECTRICAL
S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
0255273
Stop Lights Components
Ref.
2
3740049
Relay
4
3990010
Diode 6 Amp
5
0255272
Turn Signal Components
Ref.
2
2920113
Taillight
2
0901928
Bracket
2
4360089
Switch, Flasher
1
Low Oil Pressure Shutdown Electrical Diagrams
Ref.
0255274
Prior to S/N 54482
Ref.
4
0270566
S/N 54482 to Present
Ref.
1/A
2920026
Lamp, Red (At Console Box)
1
2920029
Bulb, Light
1
4360065
Switch, Oil Pressure
1
3740049
Relay
1
3990010
Diode 6 Amp
2
3740080
Relay
1
3252074
Nameplate, Engine Distress (S/N 27440 to
Present)
1
4932597
Manual Descent Electrical Diagram
Ref.
A
3990010
Diode 6 Amp
1
3990001
Diode 1 Amp
1
4360274
Switch, Push Button
1
3740049
Relay
1
0252906/1281814
Oil Cooler Electrical Diagram
Ref.
3/A
4932481
Platform Electrical Diagram (EN280 SPEC)
Ref.
I
4932941
Platform Electrical Diagram (CE SPEC) (Prior to S/N
38697)
Ref.
1
3990010
Diode - 6 Amp
15
1060012
Cable, Electrical - 12/4 (To Footswitch)
8 ft./2.5m
1060128
Cable, Shielded Electrical - 20/3 (1600153 Control
Card to Function Speed Switch)
4 ft./1.3m
3730102
Resistor - 180 ohm 1/2 watt
1
3730023
Resistor - 510 ohm 1/2 watt
1
1540003
Capacitor
1
4933045
Platform Electrical Diagram (CE SPEC) (S/N 38697
to Present)
Ref.
3
3990010
Diode - 6 Amp
20
1060012
Cable, Electrical - 12/4 (To Footswitch)
8 ft./2.5m
1060128
Cable, Shielded Electrical - 20/3 (1600153 Control
Card to Function Speed Switch)
4 ft./1.3m
3730102
Resistor - 180 ohm 1/2 watt
1
3730023
Resistor - 510 ohm 1/2 watt
1
1540003
Capacitor
1
FIGURE 7-3.
ELECTRICAL COMPONENTS AND DIAGRAM CHART (Continued)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
