SECTION 9 RECOMMENDED SERVICE PARTS STOCK
MODELS EURO 120HX
The following list will service fleets of machines (built to current production per date on the front cover) with
emergency repair parts which can be installed in the field. Parts from the list should be replaced when inven-
tory is depleted to keep service parts stock supplied. For further information, contact your JLG dealer or the
JLG Industries Parts Department.
JLG PART
NUMBER
DESCRIPTION
QTY PER FLEET
1-10
10-20
20 OR MORE
STANDARD PARTS
7000645
Coil (Figure 1-1)
1
1
1
7012730
Coil (Figure 1-2)
1
1
1
7021401
Coil (Figures 1-2 and 2-4)
1
1
1
4360314
Switch, Toggle (Figures 1-8, 2-11 and 4-4)
1
1
1
4360277
Switch, Limit (Figures 1-3, 2-1, 3-3, 3-5, 3-6 and 4-1)
1
1
1
7012906
Coil (Figure 2-2)
1
1
1
4360363
Switch, Level Sensor (Figure 2-2)
1
1
1
7017451
Coil (Figure 2-4)
1
1
1
7012943
Coil (Figure 2-4)
1
1
1
7012944
Coil (Figure 2-4)
1
1
1
4360263
Switch, Limit (Figure 2-10)
1
1
1
4360259
Switch, Proximity (Figure 2-10)
1
1
1
3740070
Relay - SPDT (Figure 2-11)
1
1
1
3740016
Relay - 3PDT (Figure 2-11)
1
1
1
3740122
Relay (Figure 2-11)
1
1
1
3740049
Relay - SPDT (Figures 2-11, 4-4 and 7-3)
1
1
1
4360216
Breaker, Circuit - 30 Amp (Figure 2-11)
1
1
1
4360232
Breaker, Circuit - 15 Amp (Figures 2-11)
1
1
1
4360112
Breaker, Circuit - 5 Amp (Figure 2-11)
1
1
1
4360470
Switch, Key (Figure 2-11)
1
1
1
2860030
Key, Replacement (Figure 2-11)
1
1
1
4360212
Breaker, Circuit - 3 Amp (Figure 2-11)
1
1
1
4360069
Breaker, Circuit - 10 Amp (Figures 2-11 and 4-4)
1
1
1
4360274
Switch, Push Button (Figures 2-11, 4-4 and 7-3)
1
1
1
4360330
Switch, Toggle (Figures 2-11 and 4-4)
1
1
1
4360328
Switch, Toggle (Figure 2-11)
1
1
1
3740123
Relay (Figures 2-11 and 4-4)
1
1
1
4360282
Block, Contact (Figures 2-11 and 4-4)
1
1
1
4360476
Block, Contact (Figures 2-11 and 4-4)
1
1
1
4360475
Switch, Push Button (Figures 2-11 and 4-4)
1
1
1
4360074
Switch, Toggle (Figure 2-13)
1
1
1
4360340
Switch, Potentiometer (Figure 2-13)
1
1
1
3990001
Diode - 6 Amp (Figures 2-13 and 7-3)
2
2
2
2120136
Element, Charge Pump Filter (Figure 2-14)
4
8
12
7004214
Element, Air Filter (Figure 2-14)
1 Dozen
1 Dozen
1 Dozen
3740059
Relay (Figure 2-14)
1
1
1
3740080
Relay (Figure 2-14)
1
1
1
3740067
Relay (Figure 2-14)
1
1
1
7008829
Board, Circuit (Figure 2-14)
1
1
1
7008828
Cable, Throttle (Figure 2-14)
1
1
1
