JLG 120HX Parts Manual - Manual (Page 203)

3120820 7-13
S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
SECTION 7 ELECTRICAL
Platform Bumpers Electrical Diagrams Ref.
0255695/1282197 Prior to S/N 43389 Ref. 5/G
0259365/1282197 S/N 43389 to Present Ref. 2/H
4360057 Switch, Limit 1
4360274 Switch, Push Button 1
3252238 Decal - Softtouch 1
3740049 Relay 2
1060341 Cable, Electrical - 16/2 12 ft./3.7m
4932621 Platform Gate Interlock Electrical Diagram Ref. A
1060300 Cable, Electrical 15 ft./4.6m
0253987 Platform Worklights Electrical Diagram Ref. 4
0254748
Platform Worklights Electrical Diagram (With
Bumpers)
Ref. 2
2920111 Light, Halogen 2
0254435/1282163 Receptacle at Platform Electrical Components Ref. 3/B
Supply Locally Cover, Receptacle 1
Supply Locally Receptacle 1
1060545 Cable, Electrical - 10/3 Options: A/R
Prior to S/N 37026 160ft./48.8m
S/N 37026 to Present 149ft/45.4m
4932482
Standard Electrical Diagram - Deutz (Prior to S/N
25609)
Ref. J
3990010 Diode - 6 Amp 20
1060341
Cable, Electrical - 16/2 (GCB to Horizontal Limit
Switch -15 ft./4.6m and Override Test Switch to Load
Management Limit Switch - 14 ft./4.3m)
30 ft./9.1m
1060016
Cable, Electrical - 16/3 (Override Test Switch to Prox-
imity Switch)
15 ft./4.6m
1060302
Cable, Electrical - 16/5 (GCB to Boom Length Mea-
suring Device)
15 ft./4.6m
4921415 Harness (Engine Terminal Strip to GCB) 1
4921416 Harness (Valves to GCB) 1
4921418 Harness (GCB to Collector Ring) 1
1540003 Capacitor 1
3730095 Resistor - 7.5 Ohm 2
4932942
Standard Electrical Diagram - Deutz (S/N 25609 to
S/N 38697)
Ref. 1
4933048
Standard Electrical Diagram - Deutz (S/N 38697 to
Present)
Ref. 1
3990010 Diode - 6 Amp 22
1060341
Cable, Electrical - 16/2 (GCB to Horizontal Limit
Switch - 15 ft./4.6m and Override Test Switch to Load
Management Limit Switch - 14 ft./4.3m)
30 ft./9.1m
1060016
Cable, Electrical - 16/3 (Override Test Switch to Prox-
imity Switch)
15 ft./4.6m
FIGURE 7-3.
ELECTRICAL COMPONENTS AND DIAGRAM CHART (Continued)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
