7-10 3120820
SECTION 7 ELECTRICAL S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
FIGURE 7-3.
ELECTRICAL COMPONENTS AND DIAGRAM CHART
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
ELECTRICAL COMPONENTS AND DIAGRAM CHART Ref.
Note: Diagrams with Asterisk (*) are shown in pre-
ceding pages. Diagrams not shown are available
from the JLG Service Department.
Alarm Wiring Diagrams Ref.
4932507
Alarms Electrical Diagram (Travel, Backup, Swing
and Descent) (Prior to April 1993)
Ref. —
0610091 Card, Circuit 1
3740049 Relay 1
4932639/1282091
Alarms Electrical Diagram (Backup, Swing and
Descent) (April 1993 to Present)
Ref. 2/C
4932638/1282091
Alarms Electrical Diagram (Travel) (April 1993 to
Present)
Ref. 2/C
3740049 Relay 1
3990010 Diode 6 Amp 2
1060341 Cable, Electrical - 16/2 11Ft/3.4m
0253077 Alarm Electrical Diagram (Tilt) Ref. 5
0140026 Alarm 1
1540002 Capacitor (Prior to S/N 38697) 1
4932635 Australian Spec Wiring Diagram Ref. D
1281819 Boom Electric Components Ref. H
1060394 Cable, Electrical - 10/4 Options:
Prior to S/N 37026 140 ft./43m
S/N 37026 to Present 149ft/45.4m
1060392 Cable, Electrical - 16/36 Options:
Prior to S/N 37026 140 ft./43m
S/N 37026 to Present 149ft/45.4m
4931961 Boom Length Indicator Electrical Diagram Ref. 1
3730024 Resistor - 100 ohms/1/2 watt 1
4932608 Broken Chain Indicator Electrical Diagram Ref. B
4932099
Drive Cut-Out Electrical Diagram - 8m (Dutch and
German Spec Only (Not Shown)
Ref. A
1060300 Cable, Electrical - 16/3 15 ft./4.6m
4120012 Socket, Relay 1
3740057 Relay - 2PDT 1
3740066 Spring, Relay 1
4932312
Drive Cut-Out Electrical Diagram - Horizontal (Ital-
ian Spec Only) (Not Shown)
Ref. A
4120012 Socket, Relay 1
3740057 Relay - 2PDT 1
3740066 Spring, Relay 1
