SECTION 5 - LCD DISPLAY PANEL - GENERATION 1 & 2
5-56 – JLG Lift – 3121261
Envelope Status
Example 1: Platform is not at the edge of the envelope
• When Unrestricted or Restricted mode is selected, the dis-
play shows envelope image in the machine status tray.
• The color code for the envelope matches the capacity
select decals on the machine.
• When the control system senses that the axles are fully
extended, the selected envelope shows up on the
machine status tray.
• The display shows animated boom length and boom
angle information along with the envelope.
• Boom movement is proportional to the envelope bound-
aries.
• Platform location is always shown at the end of the boom.
Mode Boom Platform Envelope Color
Unrestricted Orange Black Yellow
Restricted Orange Black Green
