8-4 3120676
SECTION 8 DECALS
S
E
C
T
I
O
N
8
D
E
C
A
L
S
16 1700584 Decal - Patent 1
17 Decal - Inspection Options: 1
1700593 Prior to March 1994
1702153 March 1994 to Present
18 Decal - Lift Here Options: 4
1700975 Brown & Cream (Prior to S/N 27273)
1701500 Brown & Cream (S/N 27273 to Present)
1700232 Black (Prior to S/N 27273)
1701500 Black (S/N 27273 to Present)
19 Decal - Tie Down Options: 4
1702300 Brown & Cream (Prior to S/N 27273)
1701500 Brown & Cream (S/N 27273 to Present)
1701326 Black (Prior to S/N 27273)
1702300 Black (S/N 27273 to Present)
20 Decal - Electrocution Hazard Options: 1
1700580 Prior to March 1994
1702292 March 1994 to Present
21 3252347 Nameplate - Footswitch (Prior to June 1992) 1
(was p/n 3251766)
22 3820001 Rivet 4
23 Decal - No Hands Options: 2
1700476 Prior to March 1994
1702294 March 1994 to Present
24 Decal - Attach Lanyard Options: 2
1700477 Prior to March 1994
1702512 March 1994 to June 1995
Use 1704277 June 1995 to Present (was p/n 1702612)
25 0961127 Bushing, Snap 1
26 4751400 Flatwasher 1/4” 6
27 3311405 Nut 1/4”-20NC 5
28 1060279 Cable, Lanyard 1
29 0641408 Bolt 1/4”-20NC x 1” 1
30 1700756 Decal - ADD/Full 1
31 0100010 Loctite #242 (Not Shown) A/R
32 Decal - Fuel Options: 1
1700428 Brown - Diesel
1700196 Black - Diesel
1700430 Brown - Gas
1700194 Black - Gas
1701542 Dual Fuel
33 Decal - LP Options: 1
1700429 Brown
1700197 Black
1701543 LP Gas Only
34 3252356 Decal - Dual Fuel Only 1
35 Decal - LP Options: 1
1700582 Prior to March 1994
1702293 March 1994 to Present
FIGURE 8-1. DECALS INSTALLATION - STANDARD (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
