JLG 34HA ANSI Parts Manual User Manual
Page 22
1-14
3120676
SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
65
Hardware Options:
A/R
0641404
Bolt 1/4”-20NC x 1/2” (Prior to July 1992)
A/R
2080024
Fastener (July 1992 to April 1994)
A/R
4300106
Grooved Stud (April 1994 to Present)
16
66
4761400
Lockwasher 1/4” (Prior to July 1992)
2
67
3431622
Pin, Clevis
1
68
Flatwasher 1” Options:
1
4740230
Prior to August 1994
4713000
August 1994 to Present
69
3450606
Pin, Cotter
1
70
0641608
Bolt 3/8”-16NC x 1”
8
71
4761600
Lockwasher 3/8”
8
72
1380124
Clip, Retainer (Not Shown)
8
73
4920096
Wire, Safety
A/R
74
Pin, King Options:
4
Use 3421190
ANSI (Was P/N 3421887) (Prior to S/N 24511)
3421190
ANSI & CSA (S/N 24511 to Present)
TIRE AND WHEEL INSTALLATIONS
0251261
12” x 16.5” NHX Pneumatic Tires
Ref.
0253132
8.75” x 16.5” Pneumatic Tires
Ref.
0254451
12” x 16.2” NHS Lug Foam-Filled Tires
Ref.
101
Tire & Wheel Assembly Options:
0251260
12” x 16.5” NHS Pneumatic (Left Side)
2
4520129
Tire 12” x 16.5” NHS
1
0251259
12” x 16.5” NHS Pneumatic (Right Side)
2
4520129
Tire 12” x 16.5” NHS
1
0253130
8.75” x 16.5” Pneumatic
4
4520199
Tire 8.75” x 16.5”
1
0254449
12” x 16.5” NHS Lug Foam-Filled (Right Side)
2
0254450
12” x 16.5” NHS Lug Foam-Filled (Left Side)
2
Note: Foam-filled tire and wheel assemblies are serviced
as assemblies only.
102
Rim Options:
1
4860126
12” x 16.5”
4842561
8.75” x 16.5”
103
Valve, Air Options:
1
4640113
12” x 16.5”
4640392
8.75” x 16.5”
FIGURE 1-3. FRAME, STEERING & DRIVE COMPONENTS, ASSEMBLIES & INSTALLATIONS -
FIXED & OSCILLATING AXLES (4WD)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
