SECTION 1 FRAME
.
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
FRAME WELDMENT OPTIONS:
Ref.
2360283
Frame Weldment (5’-9” With Oscillating Axle & Standard
Platform)
1
2360288
Frame Weldment (5’-9” With Fixed Axle & Standard Platform)
1
2360321
Frame Weldment (5’-9” With Oscillating Axle & Low Mount
Platform)
1
2360322
Frame Weldment (5’-9” With Fixed Axle & Low Mount Plat-
form)
1
2360330
Frame Weldment (6’-6” With 12 x 16.5 Tire Option & Oscillat-
ing Axle)
1
0251475
Frame Weldment (6’-6” With 12 x 16.5 Tire Option & Fixed
Axle)
1
AXLE INSTALLATION OPTIONS:
Ref.
0239196
Oscillating Axle - 5’-9” MACHINES (Optional - When
Equipped)
Ref.
B
0251246
Oscillating Axle - 6’-6” MACHINES (Optional - When
Equipped)
Ref.
C
0251487
Fixed Axle - 6’-6” MACHINES (12” x 16.5” Tires)
Ref.
A
1
Axle Options:
1
4843094
5’-9” Machines
4843728
6’-6” Machines
2
1681785
Lockout Cylinder Assembly - Oscillating Axle Only (See
Section 5 for Breakdown)
2
3
Hardware Options:
1
4300034
Stud (Welded on Part) (5’-9” Machines Only)
0641610
Bolt 3/8”-16NC x 1 1/4” (6’-6” Machines Only)
4
Hardware Options:
1
4751600
Flatwasher 3/8” (5’-9” Machines Only)
4740185
Flatwasher 3/8” (Hardened) (6’-6” Machines Only)
5
4761600
Lockwasher 3/8”
1
6
Top Weldment, Pin Options:
2
4842622
5’-9” Machines
4842794
6’-6” Machines
7
2160002
Fitting, Grease
1
8
4842621
Weldment, Pin
1
9
0641406
Bolt 1/4”-20NC x 3/4” (Oscillating Axle Only)
4
10
4761400
Lockwasher 1/4” (Oscillating Axle Only)
4
11
Bottom Weldment, Pin Options: (Oscillating Axle Only)
2
4842794
5’-9” Machines
4843286
6’-6” Machines
12
3311601
Nut 3/8”-16NC (5’-9” Machines Only)
1
13
Not Used
14
4751400
Flatwasher 1/4” (Oscillating Axle Only)
4
