3120676 3-3
SECTION 3 BOOM
S
E
C
T
I
O
N
3
B
O
O
M
.
FIGURE 3-1. TURNTABLE, BOOM & HORIZONTAL LIMIT SWITCH INSTALLATIONS
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
TURNTABLE OPTIONS: Ref.
4620048 Turntable - Domestic 6’-6” (Gas & Diesel) 1
4620061 Turntable - CSA 6’-6” (Gas & Diesel) 1
4620062 Turntable - Domestic 5’-9” (Gas & Diesel) 1
4620066 Turntable - Domestic 6’-6” (Electric) 1
4620067 Turntable - CSA 6’-6” (Electric) 1
4620068 Turntable - Domestic 5’-9” (Electric) 1
BOOM INSTALLATIONS Ref.
0250456 Domestic Ref. 6
0252112 CSA Ref. 2
1 0800630 Boom Assembly (See Figure 3-2 for Breakdown) 1
2 4843502 Upright, Weldment 1
3 1681840 Lift Cylinder Assembly (See Section 5 for Breakdown) 1
4 4842603 Arm Weldment - Upper 1
4A 0961024 Bushing, Oilite 2
4B 3421419 Pin 1
4C 0641420 Bolt 1/4”-20NC x 2 1/2” 1
4D 3311405 Locknut 1/4”-20NC 1
5 4842485 Arm Weldment - Lower 1
5A 0961024 Bushing, Oilite 2
5B 0961198 Bushing, Oilite 2
6 1681780 Articulate Cylinder Assembly (See Section 5 for Break-
down) 1
7 Pin (Boom Attach) Options: 1
3421752 Domestic (Prior to S/N 30067)
3422637 Domestic (S/N 30067 to Present)
3421955 CSA (Prior to S/N 30067)
3422638 CSA (S/N 30067 to Present)
8 Pin Options: 1
3421751 Domestic
3421957 CSA
9 Pin (Upright Attach) Options: 1
3421749 Domestic
3421959 CSA
10 Pin Options: 3
3422011 Domestic
3422013 CSA
11 Pin (Lower Arm/Turntable Attach) Options: 1
3421725 Domestic
3421963 CSA
12 2160002 Fitting, Grease 4
13 4751600 Flatwasher 3/8” 12
14 0641607 Bolt 3/8”-16NC x 7/8” 10
15 0100019 Loctite #271 (Not Shown) A/R
16 0641609 Bolt 3/8”-16NC x 1 1/4” 2
17 0641524 Bolt 5/16”-18NC x 3” 1
