JLG 34HA ANSI Parts Manual User Manual
Page 11
3120676
1-3
S
E
C
T
I
O
N
1
F
R
A
M
E
SECTION 1 FRAME
.
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
FRAME WELDMENT OPTIONS:
Ref.
2360274
Frame Weldment (Oscillating)
1
2360262
Frame Weldment (Fixed)
1
0238747
OSCILLATING AXLE INSTALLATION (WITH EQUIPPED)
Ref.
A
1
4842982
Axle Weldment
1
1A
0238732
Mount, Steer Cylinder Assembly (Welded on part)
2
1B
0641822
Bolt 1/2”-13NC x 2 3/4”
4
1C
4761800
Flatwasher 1/2”
4
2
4842621
Pin, Weldment
1
3
2160002
Fitting, Grease
1
4
1681785
Lockout Cylinder Assembly (See Section 5 for Breakdown)
2
5
4300034
Stud (Weld on Part)
1
6
4751600
Flatwasher 3/8”
1
7
4761600
Lockwasher 3/8”
1
8
3311601
Nut 3/8”-16NC
1
9
4842794
Pin (Bottom)
2
10
4842622
Pin (Top)
2
11
0641406
Bolt 1/4”-20NC x 3/4”
4
12
4761400
Lockwasher 1/4”
4
0238395
STEER & SPINDLE INSTALLATION (STANDARD)
Ref.
7
0252113
STEER & SPINDLE INSTALLATION (CSA)
Ref.
3
51
Spindle Options:
2
4130197
Spindle (Standard)
4160263
Spindle (CSA)
51A
0960839
Bushing, Bronze
4
52
Steer Cylinder Assembly Options: (See Section 5 for Break-
down)
1
1681814
Steer Cylinder Assembly (Prior to S/N 31941)
1683511
Steer Cylinder Assembly (S/N 31941 to Present)
53
4842860
Rod, Tie
2
54
Pin, King Options:
2
3421340
Pin, King (Standard)
3421965
Pin, King (CSA)
55
0440162
Washer, Thrust
2
56
3300012
Lugnut 1/2”-20NF
18
57
0630137
Bolt, Wheel 1/2”-20NF x 1 7/8” (Prior to July 1991)
18
58
0721004
Screw #10-24NC x 1/2”
6
59
4761000
Lockwasher #10
6
60
1120019
Cap, Hub
2
61
3322603
Nut, Slotted 1”-12NF
2
62
3450608
Pin, Cotter 3/16” x 2”
2
63
4740001
Washer, Hardened
2
64
4842624
End, Tie Rod
2
