JLG 510AJ Parts Manual - Manual (Page 86)

2-40 510AJ 3121182
SECTION 2 TURNTABLE
214 4 Bolt M10 x 25mm Options:
0701012 Belgium Built Machines S/N 1300000981 to S/N 1300001788
0771012 Belgium Built Machines S/N 1300001788 to Present
0771012 Romanian Built Machines S/N E300000100 to
S/N E300001114
215 4 Bolt M10 x 30mm Options:
0701014 Belgium Built Machines S/N 1300000981 to S/N 1300001788
0711014 Belgium Built Machines S/N 1300001788 to Present
0711014 Romanian Built Machines S/N E300000100 to
S/N E300001114
216 0711414 A/R Bolt M14 x 30mm
217 0741610 2 Screw, Countersunk 3/8in-16NC x 1-1/4in
218 0902740 1 Bracket, Engine Mounting
219 0962172 1 Bushing, Flanged
220 1320016 A/R Clamp
221 1320022 1 Clamp, Hose
222 1320222 3 Clamp, J Clip
223 1340060 1 Air Cleaner Assembly
7012664 1 Element, Air Cleaner
224 1703162 2 Decal, Fan Blade
225 1 Engine, Deutz Options:
2000273 Belgium Built Machines S/N 1300000981 to S/N 1300001788
(F3M2011 Tier II)
2000338 Belgium Built Machines S/N 1300001788 to S/N 1300003197
(F3M2011 Tier II)
1001092723 Belgium Built Machines S/N 1300003197 to Present
(D2011L03 Tier III)
1001092723 Romanian Built Machines S/N E300000100 to
S/N E300001114 (D2011L03 Tier III)
226 2060025 1 Fan
227 2200221 1 Plug (Belgium Built Machines Prior to S/N 1300003197 Only)
228 2220451 1 Fitting
229 1 Hose, 90° Elbow Options:
229A 2720434 Belgium Built Machines S/N 1300000981 to S/N 1300003196
229B 1001091179 Belgium Built Machines S/N 1300003196 to Present &
Romanian Built Machines S/N E300000100 to
S/N E300001114
230 2720449 1 Hose, Air Cleaner Intake (Belgium Built Machines Prior to
S/N 1300003197 Only)
231 2720467 2 Hose, Oil Cooler
232 2750532 380mm Hose
233 2902060 1 Battery Cable Kit C
233A 1 Cable (Battery + to Relays) Options:
7027050 Cable (Battery + to 2 Relays) (Romanian Built Machines
S/N E300001037 to S/N E300001114)
7016817 Cable (Battery + to 1 Relay) (All Belgium Built Machines &
Romanian Built Machines S/N E300000100 to S/N
E300001037)
7016820 Cable, Jumper (Relay to Relay) (All Belgium Built Machines
& Romanian Built Machines S/N E300000100 to S/N
E300001037)
FIGURE 2-10. DEUTZ ENGINE INSTALLATION (BELGIUM BUILT MACHINES S/N 1300000981
TO PRESENT & ROMANIAN BUILT MACHINES S/N E300000100 TO S/N E300001114)
ITEM # PART NUMBER QTY. DESCRIPTION REV.
