Page 154
2-108
SECTION 2 TURNTABLE
19
3380445
1
Panel, Rubber
20
3573024
1
Plate, Hinge Mounting
21
3900232
3
Capscrew, Button Head 3/8in-16NC 1-1/4in
22
Not Used
23
3960462
9ft/2.74m
Seal, Hood
24
3960464
9ft/2.74m
Seal, Hood
25
Not Used
26
4160170
1
Spring, Gas
27
4740362
6
Washer, Fender
28
4750800
12
Flatwasher #8 Regular
29
4751400
6
Flatwasher 1/4in Regular
30
4751500
2
Flatwasher 5/16in Regular
31
4751600
40
Flatwasher 3/8in Regular
32
4845194
1
Exhaust Tube Weldment
33
4846037
1
Hood Mounting Weldment
34
1
Hood Mounting Weldment Options:
Use 4341388
Prior to S/N 1300003223 (was p/n 4846670)
4341388
S/N 1300003223 to S/N 1300006659
35
4846669
1
Hood Mounting Weldment
36
3311005
4
Locknut #10-24NC
37
4751000
8
Flatwasher #10 Regular
38
4060805
6ft/1.75m
Flex-Trim
39
Not Used
40
A/R
Insulation, Heat Shield Options:
1001098567
1
Caterpillar/Perkins Engine Machines
Not Required
Deutz Engine Machines
41
4740500
3
Washer, Special (Not Used on Deutz Engine Machines)
42
4061010
1
Shield, Heat (Not Used on Deutz Engine Machines)
43
A/R
Insulation, Heat Shield Options:
1001098568
1
Perkins Engine Machines
Not Required
Deutz Engine Machines
0258430
Ref.
NOISE REDUCTION INSTALLATION (DEUTZ ENGINE
MACHINES ONLY)
2/B
101
2820099
3
Insulation, Foam
102
2820100
2
Insulation, Foam
FIGURE 2-22. HOODS INSTALLATION (BELGIUM BUILT MACHINES PRIOR TO S/N
1300006659) (CONTINUED)
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
