1-38 510AJ 3121182
SECTION 1 FRAME
124 4711400 2 Flatwasher 1/4in Thin
125 4751500 8 Flatwasher 5/16in Regular
126 4751600 A/R Flatwasher 3/8in Regular
Ref. FRAME SHIELDS INSTALLATION OPTIONS:
0272600 Ref. Belgium Built Machines Prior to S/N 1300000353 B
0273499 Ref. Belgium Built Machines S/N 1300000353 to S/N 1300003223 C
0275858 Ref. Belgium Built Machines S/N 1300003223 to Present A
0275858 Ref. Romanian Built Machines S/N E300000100 to S/N E300001114 A
201 0100011 A/R Compound, Locking
202 0641606 10 Bolt 3/8in-16NC x 3/4in
203 1 Cover (Front) Options:
4061046 Belgium Built Machines Prior to S/N 1300000353
3380504 Belgium Built Machines S/N 1300000353 to S/N 1300003223
3380764 Belgium Built Machines S/N 1300003223 to Present
3380764 Romanian Built Machines S/N E300000100 to
S/N E300001114
204 4061047 1 Shield (Rear)
205 4751600 10 Flatwasher 3/8in Regular
FIGURE 1-9. DRIVE VALVES INSTALLATIONS (CONTINUED)
ITEM # PART NUMBER QTY. DESCRIPTION REV.
