Page 78
2-32
SECTION 2 TURNTABLE
30
1
Battery (Wet)
Use 8008750
Prior to S/N 1300000238 (was p/n 0400075)
8008750
S/N 1300000238 to S/N 1300000981
31
0630498
2
Bolt, Battery Tie-Down (Prior to S/N 1300000238)
32
3311605
2
Locknut 3/8in-16NC (Prior to S/N 1300000238)
33
2200222
1
Fitting, Pipe Plug (Not Shown)
34
2220273
1
Fitting, Reducer (Not Shown) (Prior to S/N 1300000353)
35
4240099
1
Tie, Wire (Not Shown)
36
1701505
1
Decal, Diesel Fuel (Not Shown)
37
1787217
1
Clamp, Battery Hold
38
Not Used
39
0641512
2
Bolt, 5/16in-20NC x 1-1/2in
40
4751500
4
Flatwasher 5/16in Regular
41
3311505
2
Locknut, 5/16in-18NC
42
2180348
1
Fitting, Barb (S/N 1300000353 to S/N 1300000981)
43
2221176
1
Fitting, 90° (S/N 1300000353 to S/N 1300000981)
44
4922978
1
Harness, Start Assist Solenoid (S/N 1300000353 to S/N
1300000981)
Ref.
DEUTZ ENGINE ASSEMBLY OPTIONS:
0272489
Ref.
Belgium Built Machines Prior to S/N 1300000353
F
2000228
Ref.
Belgium Built Machines S/N 1300000353 to S/N 1300000981
D
101
0080231
1
Adapter, Fan Spacer
102
0100011
A/R
Compound, Locking
103
0100020
A/R
Sealant
104 to 105
Not Used
106
0340041
2
Band, Muffler Bracket
107 to 108
Not Used
109
0641406
6
Bolt 1/4in-20NC x 3/4in
110
0641410
4
Bolt 1/4in-20NC x 1-1/4in
111
0641510
3
Bolt 5/16in-18NC x 1-1/4in
112
0641608
9
Bolt 3/8in-16NC x 1in
113
0641610
16
Bolt 3/8in-16NC x 1-1/4in
114
0641812
2
Bolt 1/2in-13NC x 1-1/2in
115
0641820
4
Bolt 1/2in-13NC x 2-1/2in
116
0700816
4
Bolt M8 x 40mm
117
0701012
8
Bolt M10 x 25mm
118
0711414
6
Bolt M14 x 30mm
119
0741610
2
Screw, Flathead 3/8in-16NC x 1-1/4in
120
0902740
1
Bracket, Front Engine Mounting (Right Side)
121
0962172
1
Bushing, Flanged
122
1320016
4
Clamp, Hose
123
1320022
1
Clamp, Hose
124
1320223
3
Clamp, J-Clip 1/2in
125
1340060
1
Air Cleaner Assembly
7012664
1
Element, Air Cleaner
126
1703162
2
Decal, Fan Blade
FIGURE 2-9. DEUTZ ENGINE INSTALLATION (BELGIUM BUILT MACHINES PRIOR TO S/N
1300000981) (CONTINUED)
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
