Electrical System
9.30 266, 307 & 266 LoPro
JOYSTICK: X POSITION ±XXX% Displays position in percentage for this
axis
X NEUTRL IN NEUTRAL,
NOT NEUTRAL,
ERROR
Indicates whether joystick is in neutral
position for this axis
Y POSITION ±XXX% Displays position in percentage for this
axis
Y NEUTRL IN NEUTRAL,
NOT NEUTRAL,
ERROR
Indicates whether joystick is in neutral
position for this axis
AR ±XXX% Displays position in percentage for the
analog rocker
AR NEUTRL IN NEUTRAL,
NOT NEUTRAL,
ERROR
Indicates whether analog rocker is in
neutral position
S1 ON/OFF Displays status of S1 pushbutton
S2 ON/OFF Displays status of S2 pushbutton
S3 ON/OFF Displays status of S3 pushbutton
S4 ON/OFF Displays status of S4 pushbutton
F1 ON/OFF Displays status of F1 pushbutton
SYSTEM: GM
BATTERY XX.XV Ground module battery voltage
DATALOG: ON XXXXhXXm Displays total controller on (power) time
LIFT XXXXhXXm Displays total controller lift operation
time
FORK TILT XXXXhXXm Displays total controller fork tilt
operation time
TELE XXXXhXXm Displays total controller telescope
operation time
AUX HYD
1/2 XXXXhXXm Displays total auxiliary hydraulics 1 and
2 operation time
MAX VOLTS XX.XV Displays maximum measured battery
voltage
RENTAL XXXXhXXm Displays total controller operation time.
NOTE: can be reset
ERASE
RENTAL? Not available at password level 2.
ENTER resets rental data log time to
zero
