9.29 266, 307, 266 LoPro
Electrical System
9.13.3 Analyzer Diagnostic Help Messages
The table below lists Diagnostic Help Messages that the
Control System communicates to the Analyzer.
Diagnostics Submenu
(Displayed on Analyzer
1st Line)
Parameter
(Displayed
on Analyzer
2nd Line)
Parameter Value
(Displayed on Analyzer
2nd Line)
Description
GROUND INPUT: JYSTK
LOCK ON/OFF Display status of joystick lockout
LMI
CUTOUT ON/OFF Displays status of LMI Cutout
LMI
OVERRIDE ON/OFF Displays status of LMI Override
AUX HYD FRNT/REAR Displays if front or rear auxiliary
hydraulics is active
AUX HYD I/II Displays if aux I or aux II outlet is active
GROUND OUTPUT: TELE IN/OUT XXX% Displays telescope switch direction &
demand.
LIFT UP/DOWN XXX% Displays lift direction & demand
FORK TILT UP/DOWN XXX% Displays fork lift direction & demand
AUX HYD
1 OR 2 XXX% Displays whether Auxiliary Hydraulics 1
or 2 is active and demand percentage.
