SECTION 2 - PREPARATION AND INSPECTION
2-8
– JLG Lift – 3120736
GENERAL
Begin the “Walk-Around Inspection” at Item 1, as noted
on the diagram. Continue to the right (counterclockwise
viewed from top) checking each item in sequence for the
conditions listed in the “Walk-Around Inspection Check-
list.”
TO AVOID INJURY DO NOT OPERATE MACHINE UNTIL ALL
MALFUNCTIONS HAVE BEEN CORRECTED. USE OF A MAL-
FUNCTIONING MACHINE IS A SAFETY VIOLATION.
TO AVOID POSSIBLE INJURY, BE SURE MACHINE POWER IS
“OFF” DURING “WALK-AROUND INSPECTION.”
NOTE: Do not overlook visual inspection of chassis under-
side. Checking this area often results in discovery
of conditions which could cause extensive machine
damage.
1. Platform Controls - Properly secured; no loose or
missing parts; no visible damage to control box or
controller (joystick). Placards secure and legible;
control markings legible; operators and safety
manual in manual storage box.
2. Steer Cylinder and Linkage - Properly secured; no
loose or missing parts; no visible damage; no evi-
dence of steer cylinder leakage.
3. Safety Prop - Properly secured; no visible damage;
no loose or missing parts.
4. Scissor Arms and Sliding Wear Pads - Properly
secured; no loose or missing parts; no visible dam-
age.
5. Drive Motor, Left Front - Properly secured; no visi-
ble damage; no evidence of leakage.
6. Wheel and Tire Assembly, Left Front - Properly
secured; no loose or missing lug nuts; no visible
damage.
7. Drive Cutout Switch - Properly secured; no visible
damage; no loose or missing parts.
8. Compartment Cover and Latches - Cover and
latches in working condition; properly secured; no
loose or missing parts.
9. Ground Controls - No visible damage; switches
operable; placards secure and legible.
10. Hydraulic Reservoir - No visible damage; no loose
or missing parts; no evidence of leakage. Recom-
mended hydraulic fluid level on side of tank.
Breather cap secure and working.
11. Hydraulic Filter - No visible damage; properly
secured; no evidence of leakage.
12. Motor/Pump Unit - Properly secured; no visible
damage; no evidence of hydraulic leakage.
13. Pothole Protection System - Support bar,roll-
ers,limit switches and links properly secured; no
visible damage; no loose or missing parts.
14. Hourmeter - No visible damage.
15. Wire Installation - No visible damage; no loose or
broken wires.
16. Wheel and Tire Assembly, Left Rear - Properly
secured; no loose or missing lug nuts; no visible
damage.
17. Scissor Arms and Sliding Wear Pads - Properly
secured; no visible damage; no loose or missing
parts.
18. Manual Descent Cable and Pull Handle - No visible
damage; Properly secured; no loose or missing
parts.
19. Brake Cylinder - Properly secured; no visible dam-
age; no evidence of leakage.
20. Ladder - Properly secured; no visible damage; no
loose or missing hardware.
21. Control Valve Installation - No loose or missing
parts; no evidence of leakage; No unsupported
wires or hose; no damaged or broken wires.
22. Scissor Arms and Sliding Wear Pads - Properly
secured; no visible damage; no loose or missing
parts.
23. Wheel and Tire Assembly, Right Rear - Properly
secured; no loose or missing lug nuts; no visible
damage.
24. Lift Cylinder - Properly secured; no visible damage;
no loose or missing parts; no evidence of leakage.
25. Tilt Switch - Properly secured; no loose or missing
parts; no visible damage; no loose or broken wir-
ing.
26. Battery Installation - Proper electrolyte level; cables
secure; no damage or corrosion.
27. Pothole Protection System - Support bar, rollers,
limit switches and links properly secured; no visible
Figure 2-2. Daily Walk-Around Inspection - 1532E2/1932E2 (Sheet 2 of 3).
