Rear panel enlarged view, Audio/video systems made in the u.s.a, Caution – B&K PT 3 series II User Manual
Page 33
REAR PANEL ENLARGED VIEW
30
P/N 13010 REV 0005
TUNER
FM antenna
AM antenna
SERIAL NUMBER
Audio/Video Systems made in the U.S.A.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
www.bkcomp.com
V1
V2
TV
SOURCE INPUTS
DVD
CD
INPUT
OUTPUT
TAPE
PREAMP OUTPUTS
MONO
L+R
CONTROL
OUT
SUB
IR INPUT
ACCESSORY CONNECTION
12VDC 50mA
COMPLIES WITH THE LIMITS
FOR A CLASS B COMPUTING
DEVICE PURSUANT TO
SUBPART J OF PART 15
AC IN
B&K Components, Ltd.
2100 Old Union Rd.
Buffalo, NY 14227
www.bkcomp.com
RS-232
HIGH
PASS
FULL
RANGE
6-12VDC
38kHz
