SIDEBAR WITH BENT ENDS
2010 TOYOTA 4RUNNER WITH ROCKER COVERS
SR5 AND LIMITED MODELS
Page 3 of 3 1/18/010 (DP)
Driver Side Installation Pictured
Complete Installation
Fig 6
Fig 5
Fig 4B
Remove the (2) 8mm factory hex bolts. Gently
pull down a little on the factory rocker cover
bracket and slide the Support Bracket between
the rocker cover bracket and the body panel.
Secure with:
(2) 8mm x 25mm Hex Bolts
(2) 8mm Flat Washers
(2) 8mm Lock Washers
10mm x 25mm Hex Bolt
(2) 10mm Flat Washers
10mm Lock Washer
10mm Hex Nut
1/2" x 2" Hex Bolt
1/2" Lock Washer
1/2" Flat Washer
Front
Rear
Rear
Remove plastic deflector.
Remove plastic deflector.
Fig 4A
Driver/Left
Side Support
Bracket Passenger/
Right Side
Support
Bracket
