Aries Automotive 200002-2 User Manual
Page 4
SIDEBARS
06-11 MERCEDES BENZ ML SERIES
Page 3 of 3
3/13/13 REV1 (DP)
Driver Side Installation Pictured
Rear Bracket use:
12mm x 70mm Bolt Plate
12mm Flat Washer
12mm Lock Washer
12mm Regular Hex Nut
(2) 10mm x 30mm Hex Bolts
(4) 10mm Flat Washers
(2) 10mm Nylon Lock Nuts
Installation Complete
Front Bracket use:
12mm x 90mm Long Bolt Plate
12mm Flat Washer
12mm Lock Washer
12mm Long Coupling Hex Nut
Fig 4
Fig 5
Fig 6
