Burnham V7 SERIES - Manual (Page 41)

41
Item
No.
Description Part No. V73 V74 V75 V76 V77 V78 V79
V73 Thru V79 STEAM BOILERS - TR IM AN D CONTRO LS (See Page 40 for Illus tration)
1 . Draft Regulator
1A DR- 6 Draft Regulator 8116029 1 1 1 1 --- --- ---
1B DR- 7 Draft Regulator 8116001 --- --- --- --- 1 1 1
2. Instruction Envelope Containing:
2A Ins tallation and Oper ating Instructions 8142711 1 1 1 1 1 1 1
2B 10 Year Lim ited War ranty Mailer (Steam Boilers ) 81460121 1 1 1 1 1 1 1
2C I= B=R Pam phlet 81460061 1 1 1 1 1 1 1
3. Probe Low Wate r Cutoff
3A
Low Water Cutoff, Hy dr olevel CG450 (less probe) 80160628
1 1 1 1 1 1 1 Low W ater Cutoff, McDonnell & Miller P S-801-120 80160624
Low W ater Cutoff, McDonnell & Miller P S-804-120 80160662
3B Probe, Hydr olev el EL-1214 ( Hydrolevel CG450) 80160629 1 1 1 1 1 1 1
3C Limit, Honey well PA404A1009 80160300 1 1 1 1 1 1 1
3D Syphon, ¼ NPT x 4" x 180° 806603030 1 1 1 1 1 1 1
3D1 Bushing, ¾ NPT x ¼ NPT 806600508 1 1 1 1 1 1 1
3D2 Elbow, ¾ NPT 806601520 1 1 1 1 1 1 1
3D3 Nipple, ¾ NPT x 2" 806600003 1 1 1 1 1 1 1
3E Gage Glass S et, 6", ConBr aCo 20-104-10 8056091 1 1 1 1 1 1 1
4. Float Low Wate r Cutoff
4A Low Water Cutoff, McDonnell & Miller 67 80160597 1 1 1 1 1 1 1
4B Limit, Honey well PA404A1009 80160300 1 1 1 1 1 1 1
4C Syphon, ¼ NPT x 4" x 180° 806603030 1 1 1 1 1 1 1
4D Gage Glass S et, 6", ConBr aCo 20-104-10 8056091 1 1 1 1 1 1 1
5. Misc ella neous Trim and Controls
5A Oil Pr im ary Control, Honeywell R8184G1286 80160416 1 1 1 1 1 1 1
5B
Safety Valve, ¾ NPT, 15 psi, ConBr aCo 13-511-
08
81660530 1 1 1 1 1 1 1
5B1 Coupling, ¾ NPT 806602561 1 1 1 1 1 1 1
5B2 Nipple, ¾ NPT x 8" 806600221 1 1 1 1 1 1 1
5C Drain Valve, ¾ NPT, ConBr aCo 31-606-02 806603011 1 1 1 1 1 1 1
5C1 Bushing, 1½ NPT x ¾ NPT 806600507 1 1 1 1 1 1 1
5D Limit, Honeywell L4006A2015 (SB PT & SB FT) 80160400 1 1 1 1 1 1 1
5E W ell, ¾ NPT x 1½ ", Honeywell 123890A 80160426 1 1 1 1 1 1 1
