Installation instruction sport bar part #2550, Attention, Part list

2008-10 TOYOTA HIGHLANDER
INSTALLATION INSTRUCTION
SPORT BAR PART #2550
Page 1 of 2
ATTENTION
λ Please read this installation Menu before installing this part. NOTE: Pictures are for reference only,
actual parts may be different. Installation is the same.
λ You may need to periodically to re-tighten all hardware, such as one month or two month.
λ Please periodically check and retighten all the hardware and clean the investment for a refresh look.
PART LIST
NO. NAME QTY
REMARKS NO.
NAME QTY REMARKS
○
1
Grille guard
1
○
9
Lock Washers
2
6mm
○
2
Bracket 2 ○
10
Hex nut
2
M6
○
3
T-Bolt 1
2
M10×35
○
11
Hex bolt
4
M12×35
○
4
Big washer
2
10mm
○
12
Big washer
8
12mm
○
5
Lock Washers
2
10mm
○
13
Lock Washers
4
12mm
○
6
Hex nut
2
M10
○
14
Hex nut
4
M12
○
7
T-Bolt 2
2
M6×26
○
15
Plastic Clip
4
M10
○
8
Flat washer
2
6mm
○
16
Plastic Clip
2
M6
○
11
○
12
○
13
○
14
○
3
○
4
○
5
○
6
○
15
○
7
○
8
○
9
○
10
○
16
○
2
○
2
○
11
○
12
○
13
○
14
○
1
Install picture
