Aries Automotive 9505 User Manual
Page 7
2-1/2” SPORT BAR
2014-15 NISSAN ROGUE
EXCLUDES 2014 “SELECT” MODEL
Page 6 of 6 6/9/14
(DP)
(Fig 18) Driver side installation pictured
12mm Hex Bolt
12mm Lock Washer
12mm Flat Washer
(Fig 19A) Hold plastic cover up to bottom of brackets.
Mark location of brackets onto inside of cover
(Fig 19B) Cut as little out of the cover as possible to
clear Brackets. Cut out sections illustrated above for
example only. Actual cuts may be different
Front
Front
Front
Complete Installation
(Fig 17) Passenger side Support Bracket installed
10mm Hex Bolt
10mm Lock Washer
10mm Flat Washer
Front
