Aries Automotive 2702-2 - Manual

Page 1 of 5 5/3/2010)
PARTS LIST:
Qty Description Qty Description
1 Sport Bar 4 6mm Flat Washers
1 Driver/Left Upper Mount Bracket 4 6mm Lock Washers
1 Passenger/Right Upper Mount Bracket 4 6mm Nuts
1 Driver/Left Lower Mounting Bracket 4 8mm Flat Washers
1 Passenger/Lower Mounting Bracket 4 8mm Lock Washers
2 10mm x 30mm Bolts 4 8mm x 25mm Bolts
4 10mm Flat Washers 2 10mm x 35mm Bolt Plate
2 10mm Lock Washer 2 10mm Flat Washers
2 10mm Nuts 2 10mm Lock Washers
1 License Plate Relocation Bracket 2 10mm Nuts
4 6mm x 15mm Hex Cap Screws
INSTALLATION INSTRUCTIONS
2702/2702-2
07-09 MINI COOPER & S MODEL
2009 MINI COOPER CONVERTIABLE
08-09 MINI COOPER CLUBMAN
Driver/Left
Upper
Mounting
Bracket
Part B
Passenger/Right
Upper Mounting
Bracket Part A
Driver/Left
Lower
Mounting
Bracket Passenger/Right
Lower Mounting
Bracket
Driver/Left
Upper
Mounting
Bracket
Part B1
Passenger/Right
Upper Mounting
Bracket Part A1
Fig A License plate
re-locator
