Aries Automotive 2505 User Manual
Page 3
Page 3 of 4
5/5/2010)
11. Level and align Sport Bar properly; then tighten all hardware at this time. (Fig 7) shows install
completed
12. Do periodic inspections to the installation to make sure all hardware is secure and tight.
To protect your investment, wax this product after installing. Regular waxing is recommended to
add a protective layer over the finish. Do not use any type of polish or wax that may contain abrasives
that could damage the finish.
For stainless steel: Aluminum polish may be used to polish small scratches and scuffs on the finish.
Mild soap may be used also to clean the Sidebar.
For gloss black finishes: Mild soap may be used to clean the Sidebar.
Skid Shield removal shown from Driver/Left side
Fig 1A
Fig 1
Front
Remove bolt, 1 per side
Plastic two lower tabs
Fig 2
Remove nuts
Fig 2A
Area to cut for
bracket to slip threw
Passenger/Right side
shown
