Aries Automotive 2505 - Manual

Page 1 of 4 5/5/2010)
PARTS LIST:
Qty Description Qty Description
1 Sport Bar 1 8mm x 30mm Bolt (Mate)
1 Driver/Left Lower Mount Bracket A 1 8mm Flat Washers
1 Passenger/Right Lower Mount Bracket B 4 10mm Nuts
1 Driver/Left Lower Mount Bracket A1 6 10mm x 30mm Bolts
1 Passenger/Right Lower Mount Bracket B1 12 10mm Flat Washers
2 Passenger & Driver Upper Support Straps 6 10mm Lock Washers
1 21mm x Tow Thread Bolt
INSTALLATION INSTRUCTIONS
2505/2505-2
98-2007 SMART CAR
Driver/Left
Side
Mounting
Bracket A1 Passenger/
Right Side
Mounting
Bracket B1
21mm Tow Threaded Bolt
(pictured with 8mm flat
washer, 8mm lock washer &
8mm Bolt mate
Installed for example)
Passenger &
Driver Side
Support Strap
Driver/Left
Side
Mounting
Bracket A Passenger/
Right Side
Mounting
Bracket B
