Aries Automotive 7547 User Manual
Page 4
SPORT BAR
2011 KIA SORENTO
Page 4 of 4
8/24/10 (DP)
12mm x 35mm Hex Bolt
(2) 12mm Flat Washers
12mm Lock Washers
12mm Hex Nuts
Fig 6A
Fig 6B
(Fig 7) Pictured without splash guard in place
Front
Cut (2) slots for Mounting Bracket
clearance. Illustration is for
reference only, actual cut out
required for clearance may differ
Hard to reach tabs hidden
behind bumper cover
12mm x 40mm Hex Bolt-
through Support Bracket
(2) 12mm Flat Washers
12mm Lock Washers
12mm Hex Nuts
