Aries Automotive 7547 User Manual
Page 3
SPORT BAR
2011 KIA SORENTO
Page 3 of 4
8/24/10 (DP)
Driver Side Installation Pictured
Fig 3
Fig 4
Fig 5B
(2) 10mm x 80mm Hex Bolts
(2) 10mm x 27mm Large Flat Washers (top)
(2) 10mm x 20mm Flat Washers (bottom)
(2) 10mm Lock Washers
(2) 10mm Hex Nuts
Front
Insert hardware through these (2)
holes in the factory subframe mount
Support Bracket bolts to back of Mounting Bracket
(Fig 5A) Driver side Mounting
Bracket pictured for example
Fig 5C
