Aries Automotive
INSTALLATION INSTRUCTIONS
GRILL GUARD #1101/1101-2
2006 MERCEDES BENZ ML
PART LIST
1 GRILL GUARD
2 LOWER BRACKETS
1 MIDDLE ANGLE BRAKCT
2 UPPER BRACKETS
6 7/16 x 1 ¼” HEX BOLT
6 7/16 HEX NUT
12 7/16 FLAT WASHER
6 3/8 x 1 HEX BOLT
4 3/8 HEX NUT
12 3/8 FLAT WASHER
2 3/8 x 1 BUTTON ALLEN BOLT
2 3/8 HEX BOLT NYLOC
2 ¼ x 1 ¼ HEX BOLT
2 ¼ HEX NUT
2 ¼ FLAT WASHER
PROCEDURE:
1. REMOVE CONTENTS FROM BOX AND CHECK FOR DAMAGE. VERIFY
ALL PARTS ARE PRESENT. READ INSTRUCTIONS CAREFULLY.
2. DETACH LOWER PLASTIC LINER LOCATED IN FRONT OF VEHICLE
AND SET ASIDE ( TEMPORARILY)
3. DETACH RUBBER HOSE FROM RETAINER CLIP LOCATED ON THE
DRIVER SIDE. (SEE FIG 1.)
4. REMOVE PLASTIC RETAINER BRACKETS MOUNTED ON BRAKE LINES
ON DRIVER SIDE. (SEE FIG 2.)
5. SLIDE DRIVER SIDE BRACKET IN BETWEEN BRAKE LINES & HOSE
THEN ATTACH USING (2) 3/8 X 1 ¼ HEX BOLTS, (2) 3/8 HEX NUTS AND
(4) 3/8 FLAT WASHERS. LEAVE LOOSE. SEE FIG 1 AND FIG 2. (REPEAT
SAME STEPS ON OPPOSITE SIDE).
