Aries Automotive 4073 User Manual
Page 3
Page 3 of 3
8/10/07 (AM)
Slide Mounting Bracket
between cross member bar
and radiator support bracket
Slide Mounting
Bracket between
motor mount bushing
3/8” x 1” Self Tapping Bolt
Factory
hex nut
Factory
Bolts
8mm x 30mm Hex Bolt
8mm Nut Plate
8mm Flat Washers
Factory fastener
Remove these bolts
8mm x 20mm Button Head Bolt
8mm Nylock Nut
8mm Flat Washer
12mm x 30mm Hex Bolt
12mm Nylock Nuts
12mm Flat Washers
Fig 3
Fig 4
Fig 5
Fig 6
Fig 7
Fig 8
