Aries Automotive 4073 User Manual

Installation instructions

background image

Page 1 of 3

8/10/07 (AM)

PARTS LIST:

1 Grille Guard

2 8-1.25mm x 20mm Button Head Bolts

1 Driver/Left Mounting Bracket

2 8-1.25mm x 30mm Hex Head Bolts

1 Passenger/Right Mounting Bracket

2 8mm Nylock Nuts

1 Driver/Left Top Bracket

8 8mm ID x 22mm OD x 3mm Flat Washers

1 Passenger/Right Top Bracket

6 12-1.75mm x 30mm Hex Head Bolts

2 8mm Nut Plates

6 12mm Nylock Nuts

2 3/8” x 1” Self Tapping Bolt

12 12mm ID x 29mm OD x 3mm Flat Wahsers

INSTALLATION INSTRUCTIONS

GRILLE GUARD

08-10 GMC ACADIA

4073

Driver Side Top Bracket

Passenger Side Top Bracket

Nut Plates

Driver Side
Mounting Bracket

Passenger Side

Mounting Bracket
