2 - 2 S1930 – 0361266
Chapter 2. Specifications
Aerial Platform
Working height
25
′
(7.6 m)
Maximum platform height 19
′
(5.8 m)
Turning radius (Right turn)
Inside 5.0
″
(12.7 cm)
Outside 64.5
″
(1.64 m)
Wheelbase 4
′
6
″
(1.37 m)
Ground clearance
Pothole protector raised 2.5
″
(6.3 cm)
Pothole protector lowered 0.75
″
(1.9 cm)
Maximum wheel load 1,416 lbs (642 kg)
Maximum floor pressure 175 psi (12.3 kg/cm²)
Weight, GVW
Approximate 3,040 lbs (1,379 kg)
Stowed width 30
″
(76.2 cm)
Stowed length 6
′
2
″
(1.9 m)
With step removed 5
′
6
″
(1.7 m)
Stowed height 6
′
7
″
(2.0 m)
Platform
Dimensions
Main 29
″
x 61.5
″
(74 cm x 156 cm)
Extension 24
″
x 36
″
(61.0 cm x 91.4 cm)
Guardrail height
Main 39
″
(1.0 m)
Extension 39
″
(1.0 m)
Toeboard height 6
″
(15.2 cm)
Rated work load
Total 500 lb (227 kg)
Extension 250 lb (113 kg)
Maximum number of occupants 2 people
AC outlet 120 V, 17.4 amp
Function Speed
Platform raise
12 to 20 seconds
Platform lower 20 to 26 seconds
Drive
Platform raised less than 7
′
(2.1 m)
0 to 2 mph (0.6 to 3.2 km/h)
Platform raised more than 7
′
(2.1 m)
0 to 0.4 mph (0 to 0.6 km/h)
Drive System
Standard
2-wheel drive
Gradeability 20%
Drive/Lift Level Sensor Interlock
Side to side
2°
Front to rear 4°
Tires
Solid rubber
4
″
x 12
″
(10.2 cm x 30.5 cm)
Electrical System
Voltage
24 V DC negative chassis ground
Source 4-6 V 220 amp hour batteries
Fluid recommended distilled water
Hydraulic System
Maximum pressure
2,800 psi (19,305 kPa)
Reservoir capacity 3 US gal (11.4 l)
System capacity 3.5 US gal (13.2 l)
Maximum operating temperature 160°F (71°C)
Hydraulic fluid recommended
Above 10°F (-13°C) Mobil DTE-13M (ISO VG32)
Below 10°F (-13°C) Mobil DTE-11M (ISO VG15)
Ambient Air Temperature Operating Range
Fahrenheit
0°F to 110°F
Celsius -18°C to 43°C
General Specifications
