The aerial platform can tip over if it becomes unsta-
ble. Death or serious injury can result from a
tip-over accident. Do not open the trays when the
platform is raised more than eight feet.
To open a tray, pull outward on the latch and swing the
tray open.
Electrical Power Outlet
The electrical power outlet has two, 3-prong, 125 volt
AC electrical connectors (refer to Figure 9.6). Their
combined output is limited by a 20 amp circuit breaker.
Figure 9.6—Electrical Power Outlet
Power is supplied to the outlet by connecting an exter-
nal power source to the power-input connector at the
rear of the chassis (refer to Figure 9.7).
Figure 9.7—Power-Input Connector
To use the outlet, plug a source of power into the
power-input connector. Unplug the source of power be-
fore moving the aerial platform.
9 - 4 S1930 – 0361266
Chapter 9. Operation
Power-Input Connector
A
DANGER
