Chapter 8. Prestart Inspection
8 - 10 S1930 – 0361266
300760
300760
DANGER
Trays must be closed when platform is elevated.
TIPOVER HAZARD
300760
DEATH OR SERIOUS INJURY MAY
RESULT IF MACHINE TIPS OVER
CAUTION
Do not remove any weight from this machine Any weight added must be
distributed equally on each axle. Proper stability and axle weights of
this machine are based on the platform size shown above.
SERIAL
NUMBER MODEL
NUMBER
MAXIMUM
MACHINE
WEIGHT lbs
kg
MAXIMUM
WHEEL
LOAD lbs
kg
ENGINE
POWERED
MODELS hp
kW
BATTERY
POWERED
MODELS
ONLY V DRIVE
MOTORS
BATTERIES V
Ah
MONTH / YEAR
OF MANUFACTURE SLOPE SENSOR
ALARM SETTING deg
MAXIMUM
PLATFORM
HEIGHT
RATED
NUMBER OF
OCCUPANTS
ft
m
MAXIMUM
DRIVE
HEIGHT ft
m
UNRESTRICTED
PLATFORM
CAPACITY lbs
kg
MAXIMUM
ALLOWABLE
MANUAL FORCE
(SIDE PULL)
lbs
N
MAXIMUM
ALLOWABLE
WIND SPEED mi/h
m/s
PLATFORM
SIZE in
cm
MAXIMUM
PLATFORM
REACH ft
m
0070901
Axle weights with machine in the stowed - travel position.
lbs
lbs
kg
kg
DRIVE AXLE
STEER AXLE
0070901
300700
Left Side
451986
DANGER
DO NOT ALTER OR DISABLE
LIMIT SWITCHES, SAFETY
SWITCHES, OR INTERLOCKS.
451986
451986
0074311
Rod End of
Lift Cylinder Using incorrect parts
can cause cylinder failure.
Death or serious injury
can result.
Use only:
0074311
0074311
0361259
0361259
DANGER PROPER USE OF SAFETY PROP
TO STORE SAFETY PROP
1. Remove all material from platform.
2. Raise platform until the open height is wide
enough to position the safety prop.
3. Place safety prop in the proper position.
4. Remove hands and arms from scissors area.
5. Lower platform until scissors are supported by
safety prop.
1. Raise platform until the open height is wide
enough to position the safety prop.
2. Place the safety prop in the storage position.
0361259
Death or serious injury
might result if safety prop
is not used and/or
properly positioned. Use
safety prop at all times
when servicing machine
with platform raised.
Proper position for safety prop use
Front
300700
DANGER
300700
SHEARING HAZARD/CRUSHING HAZARD
Death or serious injury might result from having
body parts sheared or crushed as the platform
descends. Keep away from closing scissor arms
and keep out from under the platform as the
platform comes down.
0070901
On Top of Chassis
