Chapter 10 – Stowing and Transporting
34 S1930E/S1932E/S2632E – 1360460
Caution
Ratchets, winches, and come-alongs can produce
enough force to damage machine components. Do
not over tighten the straps or chains when securing
the aerial platform to the transport vehicle.
6. Use chains or straps to securely fasten the aerial
platform to the transport vehicle using the straps
through the fork lift pockets. Proper tie-down and
hauling is the responsibility of the carrier.
Winching
Use a winch to load and unload the aerial platform on
ramps that exceed the machine gradeability specification.
A winch may also be used when poor traction, uneven
surfaces, or stepped ramp transition make driving haz-
ardous.
Use the following procedure to winch the aerial platform
onto the transport vehicle.
1. Position the transport vehicle so the aerial platform
will not roll forward after it is loaded.
2. Remove any unnecessary tools, materials, or other
loose objects from the platform.
3. Move the machine to the foot of the loading ramp
with the front wheels nearest the ramp. Make sure
the machine is centered with the ramps and that the
wheels are straight.
4. Properly stow the aerial platform when finished.
Lifting With a Tail Lift
Use the following procedure to lift the aerial platform with
the aid of a Tail Lift.
1. Properly stow the aerial platform.
2. Remove all personnel, tools, materials, or other
loose objects from the platform.
3. Position the aerial platform on the tail lift.
4. Engage the brakes on both of the rear wheels.
5. Carefully raise the lift and position the aerial
platform in the transport vehicle.
6. Secure the machine to the transport vehicle using
straps through the fork lift pockets.
Securing for Transport
Use the following procedure to secure the aerial platform
on the transport vehicle.
1. Chock the wheels.
2. Remove all personnel, tools, materials, or other loose
objects from the platform.
3. Properly stow the aerial platform.
4. Place the lower controls emergency stop switch in
the off position.
5. Turn the control selector switch off and remove the
Key.
