Chapter 6 – Batteries
16 PUSH 6,8,10
6. Visually inspect the battery charge indicator for
proper charging rate. The LED’s are visible on
the left side of the lower controls. Refer to Figure 6.2
Figure 6.2 – Battery Charge Indicator
7. Leave the battery charger plugged in until it shuts
itself off. Never disconnect the cables from the bat-
tery when the charger is operating.
Note
If the charging cycle exceeds 16 hours without the
battery being fully recharged, unplug the charger
and have the battery checked.
8. After the battery charger turns itself off, it is not
necessary to immediately unplug the extension
cord from the battery charger. The charger will
monitor the charge state of the battery and
recharge them if the voltage drops off.
9 . Slide the component tray open to access the
battery. Remove the caps from the battery.
10. Visually check the battery fluid level making sure
the level is within 6 mm (¼″) of the bottom of
the filler neck inside each hole. If needed, add
distilled water.
11. Tightly replace the caps on the battery and close
and latch the component tray.
Note: Machines can also be supplied with “Maintenance
Free Batteries” , Fluid check will not be necessary on
this type of battery.
Upto 50% Charge (Flashes when charging)
Upto 75% Charge (Flashes when charging)
Upto 100% Charge (Flashes when charging)
Not Used (Gel Batteries )
